Deutz 511 Popular Diesel Engine Specs



Deutz 511 Essential Diesel Engine Bolt Tightening Torques


Deutz 511
Main Bearing Bolts

step 1 = 30 Nm
step 2 = + 30 degrees
step 3 = + 30 degrees
(total = 60 degrees)



Click for Deutz 511
engine manuals and specs

Deutz 511
Connecting Rod Bolts

step 1 = 30 Nm
step 2 = + 30 degrees
step 3 = + 60 degrees
(total = 90 degrees)



Click for Deutz 511
engine manuals and specs

Deutz 511
Cylinder Head Bolts

step 1 = 40 Nm
step 2 = + 45 degrees
step 3 = + 45 degrees
step 4 = + 45 degrees
step 5 = + 30 degrees
(total = 165 degrees)

Click for Deutz 511
engine manuals and specs


Deutz 511 Diesel Engine workshop repair Manuals and Spec Sheets



Deutz FL511 Diesel Engine Specs


Deutz F1L511
Power, displacement, bore,
stroke, weight, dimensions and
compression ratio

Power
10 kW @ 2600 rpm

Displacement
0.825 liter

Bore
100 mm

Stroke
105 mm

Weight
116 kg

Dimensions
length
500 mm

width
525 mm

height
694 mm

Compression Ratio
17.0:1

Click for Deutz 511
engine manuals and specs

Deutz F1L511W
Power, displacement, bore,
stroke, weight, dimensions and
compression ratio

Power
10 kW @ 2600 rpm

Displacement
0.825 liter

Bore
100 mm

Stroke
105 mm

Weight
116 kg

Dimensions
length
500 mm

width
525 mm

height
694 mm

Compression Ratio
19.0:1

Click for Deutz 511
engine manuals and specs


F2L511
Power, displacement, bore,
stroke, weight, dimensions and
compression ratio

Power
20 kW @ 2600 rpm

Displacement
1.65 liter

Bore
100 mm

Stroke
105 mm

Weight
155 kg

Dimensions
length
571 mm

width
525 mm

height
731 mm

Compression Ratio
17.0:1

Click for Deutz 511
engine manuals and specs

F2L511W
Power, displacement, bore,
stroke, weight, dimensions and
compression ratio

Power
20 kW @ 2600 rpm

Displacement
1.65 liter

Bore
100 mm

Stroke
105 mm

Weight
155 kg

Dimensions
length
571 mm

width
525 mm

height
731 mm

Compression Ratio
19.0:1

Click for Deutz 511
engine manuals and specs


Deutz Model Designation and Meaning


Deutz 511
Model Designation and meaning

e.g. F2L511W
F  = high speed 4 stroke engine
2  = number cylinders
L  = air cooled
5  = Deutz family name
11 = piston stroke (cm rounded up)
W  = two stage combustion
     as apposed to direct injection
	 without the W

Click for Deutz 511
engine manuals and specs
